ECE 563 Assignment 13 (due 14 April 2004)

Images for this assignment may be downloaded from impro13.zip.

Individual Projects

  1. Find the autocorrelation and selfconvolution images of an unsymmetric shape of your choice. (See example)

  2. Generate a uniform random (0-1) image the same size as your class picture (convert to grayscale). Smooth the random image with a gaussian filter whose width is 10-25% of the image. Multiply the Fourier Transform of your class image by the resulting random image applied as a phase shift. (i.e. exp(-2 j p k R(x,y)), where k is a scale factor, and R(x,y) is the random image.) Inverse transform the results and show the magnitude of the resulting images for different scale factors.

  3. Use grayscale images of two class members as input. Generate their Fourier transforms. Interchange the amplitude and phase terms of the two images and generate the corresponding inverse Fourier transform images.

Group Projects

  1. Crop out a rectangular sample from xruler.tif, showing a millimeter scale and such that the image dimensions are powers of two (e.g. 256 x 16). Determine the ruler frequency from the Fourier transform of this sample (measure the distance from the central peak (DC term) to the first strong harmonic peak). Compare the results to those determined by measuring the period (scale) directly.

  2. Rotate a small image using imrotate. Verify that the Fourier transform image rotates by the same amount by showing the rotated image and its Fourier Transform. Demonstrate with an animation.

  3. For the images of letters of the alphabet, shown below, prepare an array of images showing the cross correlation and cross convolution images of each letter with itself and the other two letters. The diagonal of this array will be autocorrelations or self convolutions.



  4. Filter the spurious patterns in the lincoln image.

  5. Use an angle-selective low-pass filter on the fabric image below to remove the structure of the individual strands and fibers. Note that most of the strands have frequencies in the horizontal and vertical directions, whereas the weave is oriented along the 45-degree axes.

  6. Prepare powerpoint tutorials on the following Matlab topics:
